Xiaomi 12 (Cupid) Test Point: A Guide to Entering EDL Mode

The Xiaomi 12 (Cupid) is a flagship device packed with powerful hardware, but like any other phone, it can encounter software issues. Whether your phone is bricked, stuck on the boot logo, or facing an FRP lock issue, entering EDL (Emergency Download) Mode can help you resolve these problems.

In this guide, we’ll cover how to locate the EDL Point Xiaomi 12 Test Point, how to use it for flashing or unlocking purposes, and when it’s required. By the end, you’ll have a clear understanding of how to bring your Xiaomi 12 back to life.

What is the EDL Test Point?

The EDL Test Point is a physical set of contact points on the motherboard that, when shorted, force your device into Emergency Download Mode. This mode is essential for repairing serious software issues, unbricking devices, or bypassing FRP locks.

The Xiaomi 12 (Cupid) has multiple variants, such as 2201123G and 2201123C, and all share the same Test Point functionality. The EDL Point cupid Test Point is specific to this series, making it a reliable solution for Xiaomi 12 users.

Why Use the Xiaomi 12 Test Point?

The EDL Point 2201123G Test Point or EDL Point 2201123C Test Point is used in cases where:

The device is hard-bricked (no response to Fastboot or Recovery mode).
FRP lock (Google account lock) needs to be bypassed.
Flashing stock firmware to fix software-related problems.
Unlocking the bootloader or resolving bootloop issues.

EDL Point Xiaomi 12 Test Point, EDL Point cupid Test Point, EDL Point 2201123G Test Point, EDL Point 2201123C Test Point

Requirements for Accessing Xiaomi 12 Test Point

Tools and Equipment:

Xiaomi 12 (model: Cupid, 2201123G, or 2201123C).
Thin metal tweezers or a conductive tool.
USB cable and PC with Qualcomm drivers installed.
Flashing tools like Mi Flash Tool or QFIL.
Official firmware for your Xiaomi 12 device.

Steps to Locate and Use the Xiaomi 12 EDL Test Point

1. Power Off Your Device

Ensure the phone is completely powered off. If it’s stuck on the boot logo, hold the power button until it powers down.

2. Open the Back Panel

Use a heat gun or hairdryer to gently heat the edges of the back panel to loosen the adhesive.
Use a plastic prying tool to remove the back cover carefully.

3. Find the Test Point

Locate the EDL Point Xiaomi 12 Test Point on the motherboard near the battery connector.
The Test Points are two small contact pads labeled on the PCB (specific to EDL Point cupid Test Point).
Refer to the image below for exact Test Point placement (Insert Picture Here).

4. Short the Test Points

Use a metal tweezer to short the two Test Points.
While shorting the Test Points, connect the device to your PC using a USB cable.

5. Verify EDL Mode

Your PC should detect the device as Qualcomm HS-USB QDLoader 9008 in Device Manager.
This confirms that your phone has successfully entered EDL mode.

6. Flash Firmware or Bypass FRP

Use Mi Flash Tool or QFIL to flash the firmware, bypass FRP, or perform necessary repairs.

Tips for Success

Backup Data Beforehand
If possible, always back up your data, as flashing firmware will erase all user data.
Check Firmware Version
Use the exact firmware for your Xiaomi 12 variant (e.g., 2201123G or 2201123C) to avoid compatibility issues.
Ensure Sufficient Battery Charge
Make sure the battery is at least 50% charged before performing the Test Point method.

Conclusion

The EDL Point Xiaomi 12 Test Point is a powerful tool for resolving software-related issues like bricked devices or FRP locks. By following the steps in this guide, you can easily enter EDL mode on your Xiaomi 12 and perform the necessary repairs.

Remember to handle the hardware carefully to avoid damaging the motherboard, and always double-check the firmware version before flashing. With this guide and the provided images, you’ll be able to revive your Xiaomi 12 in no time!
